Efficient PC Cooling Fan 2/4/6 Heat Pipe CPU Cooler Processor Installing LGA775 115x 1200 1700 1366 1356 i3 i5 i7 PWM Air-cooled

<p>Product brand: XUANFENG<br><br></p> <p>Product name: CPU cooler fan<br><br></p> <p>2 Heat pipes 1-Fan Product size: 90 (length) * 62 (width) * 140 (height) mm<br><br></p> <p>2 Heat pipes 2-Fan Product size: 90 (length) * 87 (width) * 140 (height) mm<br><br></p> <p>4 Heat pipes 1-Fan Product size: 90 (length) * 72 (width) * 145 (height) mm<br><br></p> <p>4 Heat pipes 2-Fan Product size: 90 (length) * 97 (width) * 145 (height) mm<br><br></p> <p>6 Heat pipes 1-Fan Product size: 90 (length) * 72 (width) * 145 (height) mm<br><br></p> <p>6 Heat pipes 2-Fan Product size: 90 (length) * 97 (width) * 145 (height) mm<br><br></p> <p>Fan size: 90 * 90 * 25mm<br><br></p> <p>Heat pipe specification: 6mm * 2/4/6 pieces<br><br></p> <p>3-wire speed: 2000 RPM ± 10%<br><br></p> <p>4-wire speed: 800-2000 RPM ± 10%<br><br></p> <p>3-wire current: 0.18A without lamp, 0.28A with lamp ± 10%<br><br></p> <p>4-wire current: 0.1A without lamp, 0.2A with lamp ± 10%<br><br></p> <p>3-wire power: 2W without light, 3.5W with light ± 10%<br><br></p> <p>4-wire power: 1W without light, 2.5W with light ± 10%<br><br></p> <p>Noise control: 25dBA<br><br></p> <p>Air volume: 60CFM (maximum)<br><br></p> <p>(The above data is for one fan. If there are multiple fans (air volume, noise, current, power), the data will increase.)<br><br></p> <p>Fan bearings: hydraulic bearings<br><br></p> <p>Working voltage: DC 12V<br><br></p> <p>Process materials: copper and aluminum<br><br></p> <p>Working life: 50000 hours<br><br></p> <p>Fan interface: 3Pin (3-wire constant speed)/4Pin (4-wire temperature control)<br><br></p> <p>Fan wire length: 30CM ± 10%<br><br></p> <p>Packaging method: boxed<br><br></p> <p><br><br></p> <p>Note:<br><br></p> <p>Due to manual measurement, different measurement methods and tools, there may be slight dimensional deviations.<br><br></p> <p>Due to differences in lighting, angle, and display, images may not reflect the actual color of the item<br><br></p> <p><br><br></p> <p>The following is an installation tutorial video for this product, hoping to be helpful to you. The products installed in the video are for reference only, but the installation method is the same. <br><br></p> <p><br><br></p> <p>Socket:<br><br></p> <p>For Intel: LGA 775/1150/1151/1155/1156/1200/1700/1356/1366 ( i3 i5 i7 )<br><br></p> <p><br><br></p> <p>Regarding the selection of interface types<br><br></p> <p>3Pin or 4Pin interfaces are universal and can be installed without worrying about interface types<br><br></p> <p>Fixed speed type: 3-pin fan, fixed speed, large air volume, good heat dissipation, but there may be relatively slight wind noise<br><br></p> <p>Temperature control board: The 4Pin fan will intelligently adjust the fan speed based on the current CPU temperature, which is energy-saving and silent. Extend service life! (The motherboard needs to support and enable PWM speed regulation function, which is basically available on all motherboards)<br><br></p> <p><br><br></p> <p>The following is a tutorial on installing the LAG: 775/115x/1200/1700/1356/1366 CPU cooling fan. The product in the picture may be different from the one you purchased, but the installation method is the same.<br><br></p> <p></p>
